Fluke | 1662

Installation tester: continuity, RCD test, insulation, earth by loop

Fluke
Reference : FLU1662
Serie : 1660, 1652C, 1663, 1664FC, 166x
Purchase Order Reference : FLK-1662 SCH
Brand : Fluke
NOUVEAU:
Nouveau cordon prise secteur avec "pod" spécial de connexion.
---------------------
Conformités: EN61557/VDE0413/NFC15-100.
Mesure de continuité sous 250 mA & 10mA
Contrôle des disjoncteurs différentiels A, AC - calibres: 10, 30, 100, 300, 500, 650 mA et 1 A
Mesure d'isolement sous une tension d'essai de 500 V
Mesure de terre par méthode des boucles, avec ou sans déclenchement des disjoncteurs
Mesure de tension

- Simplicité : tournez le bouton rotatif, appuyez sur le bouton de test et lisez le résultat
- Sécurité et facilité : Sonde de télécommande déportée, pas de menus
- Confort : compacité et légèreté (moins de 1,2 kg) pour une utilisation quotidienne
TTCHT
Quantity
En Stock
Quick quote for this product
Quick quote for this product
Details

Fluke  1662



The Fluke 1662 gives you Fluke reliability. simple operation and all the testing power you need for day-in. day-out installation testing.

The 1662 puts more power in your hands by quickly and efficiently testing to all local regulations.

  • Continuity at 250mA & 10mA
  • Voltage & frequency
  • Wiring polarity checker. detects broken N wires
  • Insulation resistance
  • Continuity & resistance
  • Measure motor windings with continuity test
  • Loop & line resistance
  • Prospective earth fault current (PEFC/IK)
  • Prospective short-circuit current (PSC/IK)
  • RCD switching time
  • RCD tripping level (ramp test)
  • Measures trip time & current for RCD type A. AC in one test
  • RCD variable current
  • Automatic RCD test sequence
  • Phase sequence indicator
  • PC interface. reports... with optional FlukeView® Forms software kit (see options)

Package include
1 Fluke 1662 installation controller
1 padded neckstrap
6 1.5V LR06 (AA) batteries
1 remote control probe
1 set of 3 leads. 3 touch points & 3 alligator clips
(colors: red. green. blue)
1 schuko cord for tests in wall sockets
1 zero adapter
1 reinforced carrying hardcase
1 multi-languages user manual on CD
+ 1 quick guide in english
1 verification official report with measures table

Product Details
41-Standard Manufacturer Warranty 3 YEARS
103-Differential test (A) 10mA | 30mA | 100mA | 300mA | 500mA | 1000mA | 650mA | adjustable range
91-Leads compensation (Y/N) Yes
102-Method of Earth measurement (Type) Without rod
426-Measures Undervoltage | Outvoltage
94-Test voltage (V) 100 V | 250 V | 500 V | 1000 V
81-Insulation min (Ohm) 10 kOhm
101-Measure (Type) Earth | Continuity | differential test | Insulation
82-Insulation max (Ohm) 1 GOhm
80-Voltage measure max (V) 500 V AC
25-Autonomy nc
119-Safety Level CAT I | CAT II | CAT III
120-Safety Overvoltage CAT III 500 V
36-Additional Characteristics Phase sequence.RCD tripping current level (ramp test).Leads compensation.Complies with EN61557/VDE 0413/NFC 15-100.
542-Metrology/Quality documentation supplied Verification official report (with measures table)
132-Package includes 1662 tester, 6 AA 1.5V batteries, 1 neck-strap, 1 set of test leads TL165x (3 leads, 3 touch points, 3 alligator clips), 1 remote probe with test button TP165x, 1 main test cord, 1 0 adapter, 1 carrying hardcase, 1 multilanguages user manual on CD, 1 quick ref guide in english, 1 verification official report+ OFFER, the FVF-SC2 Fluke software
35-Dimension (HxWxD) (mm) 100x250x125 mm (1662)260x390x200 mm (Hardcase)
13-Net Weight 1.3 kg (1662 only)
