Fluke | 719Pro

Handheld pressure calibrator, electric pump, pressure & 0-24mA current sourcing

Fluke
Reference : FLU719Pro
Serie : 71x
Brand : Fluke
Le 719Pro possède un calibrateur de boucles qui, entre autres, génère, simule et mesure des signaux de l'ordre du mA. Il est donc l'outil de test idéal pour la calibration des émetteurs, des contacteurs de pression et des jauges de pression de haute précision.

Pompe électrique intégrée.
Génère pression & courant.
Mesure pression, courant et tension DC.
Gammes de pression de 30 psi (2 bar), 150 psi (10 bar) et 300 psi (20 bar) en fonction du modèle (choix en option).
Précision: 0.025%.
Gamme de mesure de pression extensible par modules en option.
Courant: 0-24mA, précision: 0.015%.
Tension: 30 Vcc, précision: 0,015 %.
Température: -50 à +150°C, précision 0.1 °C .
TTCHT
Quantity
Expédié sous 2 semaines
Quick quote for this product
Quick quote for this product
Details

Fluke 719Pro

The 719Pro includes a full functioning loop calibrator that sources. simulates and measures mA signals and more making it the ideal test tool for calibrating high accuracy transmitters. pressure switches and pressure gauges.

Get the ultimate in measurement flexibility with the large backlit screen. which displays three parameters at once:

  • Pressure measurement from internal or external sensor
  • Sourced/simulated or measured mA values
  • Temperature measured by optional RTD probe

Key Features:

  • Unique integrated electric pump for one handed pressure calibration
  • Test pressure switches easily with easy-to-use switch test function
  • Precision pressure adjust vernier for easy and accurate pressure calibration
  • Ideal accuracy and performance (0.025 %) for reference class transmitter calibration
  • 30 PSI. 150 PSI and 300 PSI pressure ranges
  • Programmable pressure calibrator pump limit:
    • Eliminates over-pressurization
    • Allows the user to program target pressures for pumping
  • Extended pressure measurement range with any of 29 700Pxx Pressure Modules
  • Pump cleanout ports reduce pump failures from moisture and fluid damage
  • Fluid trap included with the unit to mitigate chance of fluid damage in at-risk applications
  • Precision temperature measurement with optional RTD probe



Specifications
Pressure Measurement
Range-12 to 300 PSI / -0.8 to 20 bar
Resolution0.01 PSI. 0.001 bar
Accuracy (1 year)± 0.025 % of full scale. 6 months ± 0.035 % of full scale.
1 year Dry Air and non-corrosive gas only
Temperature effect (all ranges)Add ± 0.002 % F.S./°C for temps outside of 15 °C to 35 °C
No effect on accuracy on all functions from 15 °C to 35 °C
FunctionRangeResolutionAccuracy (1 year)Comment
mA dc (simulation and measurement)0-24 mA dc0.001 mA± 0.015 % of reading ± 2 counts1000 ohm maximum load in mA source. 26 V dc maximum voltage in mA simulate
Volts dc (measurement only)30 V dc0.001 V± 0.015 % of reading ± 2 countsNo AC voltage measurement. do not exceed 30 V dc
Temperature (measurement only. Pt100 RTD)-50 to 150 °C (-50 °F to 302 °F)0.01 °C 0.01 °FTemperature ± 0.1 °C (0.2 °F)± 0.25 °C (± 0.45 °F) combined uncertainty when using 720 RTD probe (optional accessory)
Loop power supply24 V dcN/A24 mA at 24 V
Temperature effect (all functions)  Add ± 0.002 % F.S./°C for temps outside of 15 °C to 35 °CNo effect on accuracy on all functions from 15 °C to 35 °C
Environmental
Operating temperature-10 °C to +50 °C
Storage temperature (with batteries)Per battery manufacturer's specification within storage specification below
Storage temperature (without batteries)-20 °C to +60 °C
Power Requirements
BatteryEight (8) standard Alkaline AA batteries
Battery life300 pump cycles to 150 PSI minimum; 1000 pump cycles to 30 PSI; 100 pump cycles to 300 PSI minimum
Physical
Dimensions (HxWxD)24.13 cm x 11.18 cm x 7 cm (9.5 in x 4.4 in x 2.8 in)
WeightWith holster 1.2 kg (2.5 lb)
Connections
Pressure1/8 inch female NPT
ElectricalStandard banana jacks
RTD4 pin miniature circular
External module6 pin miniature circular
Engineering Units (Configurable)
psi. bar. mbar. kPa. kgcm2. cmH2O@4 °C. cmH2O@20 °C. mH2O@4 °C. mH2O@20 °C. inH2O@4 °C. inH2O@20 °C. inH2O@60 °F. mmHg@0 °C. inHg@0 °C. ftH2O@4 °C. ftH2O@20 °C. ftH2O@60 °F

Product Details
41-Standard Manufacturer Warranty 3 YEARS
420-Measures ranges
  • 719Pro-30G: -850 mbar to 2 bar.
  • 719Pro-150G: -850 mbar to 10 bar.
  • 719Pro-300G: -850 mbar to 20 bar.
  • Modules supplémentaires: 700 Bar max.
421-Generated ranges
  • 719Pro-30G: -850 mbar à 2 bar.
  • 719Pro-150G: -850 mbar à 10 bar.
  • 719Pro-300G: -850 mbar à 20 bar.
411-Measurement/generate (type) mA
24-Accuracy (%) 0.015% (mA); 0.025% (Bar, PSI)
36-Additional Characteristics Pressure & current (0-24mA) sourcing & measurement.Voltage (30 V DC) measurement.Temperature (-50 to +150°C) measurement with optional RTD probe.Electrical pressure pump.Fluid trap included with the unit to mitigate chance of fluid damage in at-risk applications.
542-Metrology/Quality documentation supplied Calibration certificate (With measures table)
132-Package includes Test leads with alligator clips, printed users manual and users manualon CD-ROM in 14 languages, fluid trap, carrying case, 1/4 inch NPTto ¼ inch ISO adapter, accessory hose kit with (2) 1/8 inch quick fitadapters and 1 meter of hose, Traceable Certificate of Calibration.
35-Dimension (HxWxD) (mm) 24,13 cm x 11,18 cm x 7 cm (9,5 " x 4,4 " x 2,8 ")
13-Net Weight With holster 1.2 kg (2.5 lb)
