Aaronia | BicoLOG 5070

Biconical radial isotropic broadband antenna, 50MHz-700MHz, -18dBi

Reference : AARBicoLOG5070
Serie : Spectran, BicoLOG
Brand : Aaronia
Antenne CEM à large bande biconique radiale isotrope
Appropriée pour les analyseurs de spectre de toutes les marques de fabrication
Modèle: biconique (radiale isotrope)
Gamme de fréquence: de 50MHz à 700MHz
Puissance d´entrée max: 5W AM (100MHz)
Impédance nominale: 50 Ohm
Gain : -18dBi (@100MHz)
Facteur d´antenne: voir fiche technique
Connexion HF: SMA (f) ou N via l'adaptateur
Connexion trépied: 1/4"
Points d´étalonnage: 70 (intervalles de 5MHz et 10MHz)
Dimensions (L/L/H): 350x160x140mm
Poids: 350gr
Garantie: 10 ans
Expédié sous 2 semaines
Quick quote for this product
Quick quote for this product

BicoLOG 5070

Biconical radial isotropic broadband antenna


Excellent cost effective antenna for low frequency measurements. Perfect to cover the full radio & TV frequency band down to 50MHz including Tetra/BOS & ISM434.


Every BicoLOG antenna goes through rigorous testing in our laboratories before dispatch and is equipped with a high quality rubber paint which offers protection against mechanical damage and environmental influence. a top-quality integrated tripod connection and a SMA connector.


Made in Germany:

All Aaronia antennas are developed. individually produced and calibrated in Germany at the Aaronia factory. This guarantees highest standard so that Aaronia can offer every customer a full 10 years warranty for all EMC antennas.


Exhaustive Calibration data:

All Aaronia antennas include a complete high resolution (10MHz or even 5MHz steps!) calibration data set with an unmatched number of calibration points (on CD). This offers the ability to make a very accurate EMC measurement with any Spectrum Analyzer.


Optional Accessories:

Each BicoLOG antenna can be equipped with many accessories like a rugged carrying case etc.. More details can be found at above section "Accessories".


  • Compatible with any Spectrum Analyzer brand
  • Design: Biconical (radial isotropic)
  • Frequency range: 50MHz to 700MHz
  • Max. input power: 5W AM (100MHz)
  • Nominal impedance: 50 Ohm
  • Gain: -18dBi (@100MHz)
  • Antenna factor: See data sheet graph
  • RF connection: SMA (f) or N (see optional adapter)
  • Tripod connection: 1/4"
  • Calibration points: 70 (5MHz and 10MHz-steps)
  • Dimensions (L/W/D):
  • Weight: 350gr
  • Warranty: 10 years



  • Excellent cost effective choice for low frequency measurements down to 50MHz
  • Typical standard calibration data (on CD)
  • Coverage of various mobile radio frequency ranges
  • Suitable for field-strength and EMC measurements due to high precision
  • Compact design
  • Can be used in the lab and for open-field application


Examples for possible analysis and measurements within frequency range (50MHz - 700MHz):

  • Radio & TV
  • Tetra/BOS
  • ISM434
  • etc.


Included in delivery:

  • BicoLOG 5070 radial isotropic biconical antenna
  • Typical calibration data with 70 calibration points (5MHz and 10MHz steps!) on CD
  • Carrying case not included! Please order it separately!
Product Details
41-Standard Manufacturer Warranty 10 YEARS
699-Antenna type Biconical
700-Active or passive antenna ? Passive
701-Directional ? No
240-Frequency (min) 50 MHz
235-Frequency (max) 700 MHz
613-RF Connector SMA
132-Package includes Calibration datas on CD
35-Dimension (HxWxD) (mm) 350x160x140 mm
13-Net Weight 350 g
